THEWATERSYSTEM
14a. THE UNICORN III SINGLE
AXLES AND PEGASUS GT65
WATER SYSTEM
Water Supply
These models are supplied with a 12v
submersible pump, controlled by a pressure
switch. The water inlet is located in the off-
side exterior wall, protected by a lift up
lid. This pump is designed to simplify, the
connectionofanoutsidewatersupplytothe
caravansystem.
The Whale Watermaster comprises a
wall socket, plug complete with hose and
submersible pump. The plug and socket
combine both the water and electric
connections. Designed for pumping fresh
waterintothecaravan,theWhaleWatermaster
isalsocapableofsupplyingwatertoawater
heater.
Operation
• Openonecoldtap(e.g.thekitchensink)
• Placethepumpintoawatercontainer
•Insert the plug into the wall socket and
closethelidtolockpluginplace.
• Adjust the dust cover over the opening in
container(pleasenote:thedustcovershould
notbesecuredtowatercontainerasairmust
be allowed to enter the container to replace
thewaterbeingpumpedout)
• Switch on 12 volt supply at main panel
(isolatorswitch)
• Waterwillowfromtheopentapexpelling
anytrappedairinafewseconds
• Turnoffthetap;thesystemisnowreadyfor
use
i
Thepumphosecanbeinsertedinto
thegrooveontheplugtokeeppump
offthegroundwhilerefuellingthe
watercontainer
Removingtheplug:
•Switch off the 12v supply at the control
panel(isolatorswitch)
•Pulloutplugfromsocketusinghandgrip
•Shutthelid.
•Donotrunpumpwithoutwater.
•Donotusethepumpinwatertemperatures
above40°C(100°F)
•Itisbesttostandthepumpverticallyinthe
