62
HEATINGSYSTEMS
20. HEATING SYSTEMS
ALDE HEATING SYSTEM
!
Alwaysreplacetheheattransferuid
(HTF)inaccordancewiththe
antifreezeproduct’slifespan.Ifinany
doubt,replacetheHTFafter2years.
The corrosion inhibitors found in ethylene
glycolantifreezemaynotbecross-compatible.
WhentoppinguporreplacingtheHTF,ensure
the new antifreeze is compatible with the
currentantifreezeproduct.Readtheproduct
labelorcontacttheproductmanufacturerfor
details.
Operating Instructions: 3020 Compact High
Efciency Boiler
!
Aldecanacceptnoliability
whatsoeverfordamageorinjury
resultingfromfailuretoobservethese
instructions.
SpeciedUse
TheseinstructionsareapprovedfortheAlde
3020 Compact HE boiler tted in caravans,
motorhomes or buildings in accordance with
CE0402no.SC0653-13,andhavetheE5mark
forinstallationinvehiclesinaccordancewith
ECER122,no.00001andR10,no.04166,for
useincentralheatingandhotwatersystems.
Theboilerisnotintendedforusebypersons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and/or knowledge, unless they
havebeengiveninstructionoraresupervised.
The term “specied use” also covers
observance of the operating and installation
instructions.
The Alde 3020 Compact HE boiler must be
installedorrepairedbyacompetentpersonin
accordancewithcurrentlocalregulations.
Intheunlikelyeventthatyourboilerdevelops
afault,switchofftheboilerandcontactAlde,
oryourdealerorinstaller.
Operatingandinstallationinstructionsforthe
Aldecontrolpanelaresuppliedseparately.
The owner is always responsible for
maintenanceandarranginginspection.
BoilerDesign
Theboiler’sinternalheatexchangerconsists
ofthreeconcentriccylinders:thecombustion
chamber,thecentralheatingcylinderandthe
hotwatercylinder.
The combustion chamber is made from
aluminium, and is divided into two halves by
a bafe plate, with the burner head located
in the top half, and the ue gases venting
throughthebottomhalf.
Thecombustionassemblyisxedtotheend
of the internal heat exchanger. It consists
of the burner, combustion fan, gas valve, air
intakeandexhaustducts,andgasline.
Two electric heating elements are sealed
inside the central heating cylinder, one for
1kW,onefor2kW.
Description of Functions
Gas Heating
Whengasheatingissetto“On”thecombustion
fanstartstorevolve.Oncethecorrectspeedis
achieved(inrpm),asignalissenttothePCB
(Printed Circuit Board) for the burner to be
lit.Thegasvalveopens,passinggas,andthe
ignitionmoduleonthePCBgeneratessparks
attheelectrodeontheburnerhead.
Whentheburner ignites,a amesupervision
device (FSD) signals the ignition module to
cease sparking. The burner res until the
boilerorroomthermostatreachtheset-point.
Shouldtheburnerameoutunexpectedly,the
FSDdetectsthisandattemptstoreignite(for
about10 seconds),beforeshuttingdownand
raisingafaultcode.
i
Listen carefully to the ignition
sequenceoftheboiler.Youshouldhear
the whirl of the combustion fan, the
clunkofthegasvalveandthetick-tick
oftheignitionmodule.
Electric Heating
When electric heating is set to 1, 2 or 3kW,
relays on the PCB trip, feeding the 230 v
supplytotheelectricheatingelements.These
arecontrolledbythesameprogrammeasthe
gasheating.
Domestic Hot Water
Thecombi-typeboilerautomaticallyproduces
hot water. Heat is emitted from the central
heating cylinder into the hot water cylinder.
If the hot water cylinder is empty, the air is
heatedbutnodamagecanresult.
