baxter Hillrom Proqressa+ - Vertical Oxygen Tank Holder; Kinetec Oxygen Tank Holder

Accessories
Progressa+ Bed Instructions for Use (216321 REV 2) 95
VERTICAL OXYGEN TANK HOLDER
WARNING:
Warning—Each vertical oxygen tank holder safe working load is 30 lb (13.6 kg). Exceeding the safe
working load can cause injury or equipment damage.
KINETEC OXYGEN TANK HOLDER
The Kinetec oxygen tank holder is a removable tank holder that can be installed at the head end of the
bed, in the left or right IV pole sockets. The oxygen tank holder accommodates cylinder type B5 with a
regulator.
WARNING:
Warning—Make sure the headboard is installed when the oxygen tank holder is in place. Patient injury
may occur.
To Install
Install the oxygen tank holder in the left or right IV pole socket. Make sure the openings in the
holder align with the space in the bed frame.
To Remove
Lift the holder out of the IV pole socket.
The oxygen tank holders are located in the head end corners of
the upper frame. The blue sleeve holds a steel tank, and the gray
sleeve holds an aluminum tank. Each oxygen tank holder
accommodates one D-size or E-size oxygen tank with a regulator.
To Install
Install the oxygen tank in the holder. Depending on the date of
manufacture, the holder will have either a rigid plastic bottom or a
spring-loaded metal support cage.
If the holder has a spring-loaded metal support cage, make sure that
the support cage completely lowers when you install the tank.
To Remove
Lift the tank out of the holder.
NOTE:
A blue insert sleeve is required for steel oxygen tanks. A gray insert
sleeve is required for aluminum oxygen tanks.
