Technical Specifications
122 Progressa+ Bed Instructions for Use (216321 REV 2)
•On
•Auto
•PSK
•WPA-TKIP
•WPA2-PSK
• WPA2-AES
•CCKM-TKIP
• CCKM-AES
• WPA-PSK-AES
• WPA-AES
Extensible Authentication Protocol Types (EAP Types)
• PEAP-MSCHAP
• PEAP-GTC
The current firmware for the Progressa+ Beds WiFi (internal wireless module) interface does not
support 802.11r fast transition authentication key management (AKM)—fast transition-pre-shared key
(FT-PSK) or 802.1x-FT. Cisco/Meraki wireless local area networks (WLANs) on which
Progressa+ Beds
will be connected that use 802.11r must have their AKM modified to Fast Transition: Adaptive. For other
WiFi vendors, please refer to their documentation for adaptive, fast transition AKM strategies.
Wireless System Characteristics
Characteristic
Description
Frequency Band—2.4 GHz FCC: 2.4 GHz to 2.483 GHz
ETSI: 2.4 GHz to 2.483 GHz
MIC: 2.4 GHz to 2.495 GHz
KC: 2.4 GHz to 2.483 GHz
Frequency Band—5GHz FCC: 5.15 GHz to 5.35 GHz, 5.725 GHz to 5.825 GHz
ETSI: 5.15 GHz to 5.35 GHz, 5.47 GHz to 5.725 GHz
MIC: 5.15 GHz to 5.35 GHz, 5.47 GHz to 5.725 GHz (W56)
KC: 5.15 GHz to 5.25 GHz, 5.725 GHz to 5.825 GHz
Modulation
BPSK @ 1, 6, 6.5, 7.2, and 9 Mbps
QPSK @ 2, 12, 13, 14.4, 18, 19.5, and 21.7 Mbps
CCK @ 5.5 and 11Mbps
16-QAM @ 24, 26, 28.9, 36, 39, and 43.3 Mbps
64-QAM @ 48, 52, 54, 57.8, 58.5, 65, and 72.2 Mbps
Network Standards
IEEE 802.11a, 802.11b, 802.11d, 802.11e, 802.11g, 802.11h,
802.11i, 802.11n
Data Rates Supported 802.11a (OFDM): 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b (DSSS, CCK): 1, 2, 5.5, 11 Mbps
80211g (OFDM): 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (OFDM, HT20, MCS 0-7): 6.5, 13, 19.5, 26, 39, 52, 58.5, 72.2 Mbps and 7.2,
14.4, 21.7, 28.9, 43.3, 57.8, 65 Mbps
Transmit Power Settings
802.11a: 6 Mbps 15 dBm, 54 Mbps 13 dBm (PER - 10%)
802.11b: 1 Mbps 16 dBm, 11 Mbps 16 dBm (PER - 10%)
802.11g: 6 Mbps 16
dBm, 54 Mbps 14 dBm (PER - 10%)
802.11n (2.4 GHz): MCS0 Mbps 16 dBmMCS7 Mbps 12 dBm
80211n (5 GHz): MCS0 Mbps 15 dBm, MCS7 Mbps 12 dBm
