Bed Frame Features
72 Progressa+ Bed Instructions for Use (216321 REV 2)
There are three steer systems available on the bed: Corner Steer, 5
th
Wheel, and IntelliDrive Transport
System.
To Activate
Corner Steer: The left foot-end caster locks in-line ready for system movements.
5th Wheel: When the brake and steer pedal is placed in steer, the front casters are not locked into steer
mode. All four casters on the bed are put into the neutral position. This allows the bed to pivot on the
5th wheel. Pivoting on the 5th wheel, allows for tighter turns, and enhanced ease of steering.
IntelliDrive Transport System: Steer mechanism operates as above in 5th wheel only with a power
drive wheel.
When the bed is connected to AC power and the brakes are not set, an alert sounds and a message
shows on the GCI screen. When AC power is removed, the alert will stop and the GCI screen will turn off.
Brake (orange pedal)—
Step down on the orange
brake pedal until it stops.
Push and pull on the bed
to make sure that the
brake function is fully
engaged.
Neutral Position—Move the
brake or steer pedal to the level
position.
The bed can now be moved in
any direction.
Steer (green pedal)—
Step down on the green
steer pedal until it stops.
The left foot-end caster
locks in-line.
