182 BD FACSCanto II Instructions for Use
Table 10-1 Correspondence of cytometer ports to fluidics cart ports
Port or Button on Cytometer Port on Fluidics Cart
a. System Power —
b. Power Out k. Power In
c. Air In m. Air Out
d. Waste (A) o. Waste
e. Communications j. Communication
f. Sheath (B) i. Fluid Out
g. Waste (A) n. Waste
— h. On/Off
— l. Air In
Do not plug the fluidics cart power cord into a wall outlet. Plug the cord
into the cytometer only. This ensures proper electrical grounding and
protects against electrical shock or damage to the cytometer.
Table 10-2 Function of ports, buttons, and switches
Port or Switch Additional Information
a. System Power Powers both cytometer and fluidics cart
b. Power Out Connects to fluidics cart
c. Air In 70±5 psi
d. Waste (A) Waste out (aspirated)
e. Communications Data port
f. Sheath (B) BD FACSFlow solution port
g. Waste (A) Waste out (non-aspirated)
h. On/Off Auxiliary air supply switch. Keep in off
position unless connected to house air.
