Chapter 10: Maintenance 181
Reconnecting the Fluidics Cart Tubing
Tip The ports and connectors are color coded.
Figure 10-9 Cytometer and fluidics cart ports
Cytometer ports and their corresponding fluidics cart ports are listed in
Table 10-1 on page 182. See Table 10-2 for port functions.
f
g
d
c
b
a
e
i
m
j
k
o
n
h
l
cytometer ports fluidics cart ports
