Chapter 1: Introduction 27
Barcode Reader (Optional)
The Opticon LG2 Imager is a hand-held barcode reader that plugs into the USB
port on the BD FACSCanto II computer workstation.
The barcode reader reads most barcode standards, including Codabar, Code 128,
Code 39 with checksum, and PDF417. It reads information from the BD FACS™
7-color setup beads label into BD FACSCanto clinical software, and also reads
coded patient information into a worklist. For operating instructions, see
Chapter 3 on page 39.
Figure 1-9 Typical barcode reader (example)
ready light
view from top
trigger
