BD FACSCanto II - Page 185

Chapter 10: Maintenance 185
5 Put a new level sensor assembly on the cubitainer or waste container.
Hand-tighten the cap until it is fully closed.
Figure 10-10 Level sensor assemblies
6 Reattach the sensor line and fluidics lines.
7 If you replaced any level sensors (other than the waste sensor), prime the
affected fluidics lines.
Important: Continue with the procedure in Priming Fluidics Lines on
page 169.
To ensure that the appropriate solutions are dispensed, make sure the label
on the container matches the labeled port on the fluidics cart.
waste level sensor
(red connector)
BD FACSFlow level sensor
(blue connector)
BD FACSClean solution and
BD FACS shutdown solution
level sensor (yellow connector
)
