Calibrating Instruments - 79
If RTD Temperature or TC Temperature is selected, the option Automatic
Control will appear. Calibrator will set the calibration points.
Continue the instrument setup by modifying several pages of instrument
configuration data. Note that by default only basic pages are shown. View
all pages by selecting Show, All Pages from the menu available when
creating/editing an instrument.
Basic pages
First page of the creating new instrument configuration data is Input
related. For all input quantities (except Keyed option), parameters Port /
Function and Unit are available. Depending on selected Quantity and
Port / Function, other fields will become available for setup (see table
Table 1: Input parameters depending on the selected Quantity).
Table 1: Input parameters depending on the selected Quantity
Quantity Additional available settings
RTD Temperature Sensor Type, Automatic control
TC Temperature Sensor Type, RJ Mode, Automatic
control
Pressure Pressure Type
Current Loop Supply
Frequency Amplitude, Waveform & Duty Cycle,
Trigger Level
Pulse Amplitude, Waveform & Duty Cycle,
Frequency, Trigger Level, Trigger
Edge
Keyed Keyed Quantity, Unit, Resolution,
Resolution from Entry
