9.5 N1/T1 Docking Station
9.5.1 Maun Unit
9.5.1.1 Exploded View
9.5.1.2 Parts List
No. Order Number Part Description Qty Remarks
1 115-050764-00 DOCK Top Shell Module(ESM)(FRU) 1 Compatible with 115-021128-00
2 051-001368-00 T1 DOCK connector Board PCBA 1 /
3 115-018066-00 right shell module of DOCK 1 /
4 043-003180-00 Dock Bottom Housing 1 /
9.5.2 Dock Top Housing Assembly
9.5.2.1 Exploded View
