3-8
Table 3-3 Patient monitor installation confirmation table
Test or Observation Item Result (Pass, Fail or NA)
Execute the Ping command on the central monitoring system for the patient monitor.
Make sure that the average delay is less than 250 milliseconds, and the packet loss rate is
less than 1%.
Hold the patient monitor to walk around in different AP scopes. Observe the continuous
waveform on the central monitoring system after walking about in the entire expected
coverage area. The offline event time should be less than 10% of the patient monitor
roaming time.
At the position with the worst coverage effect, the RSSI value on the screen is higher
than -65 dBm.
If the evaluated monitor has a fixed position and does not roam between APs, the test of walking in the
coverage area is not required. You only need to place the monitor at the position with the worst signal
where it may be installed, and then confirm the RSSI and ping effect.
3.6 Recommended Network Devices
CISCO devices listed below are recommended.
Device Part No.
2500 wireless controller AIR-CT2504-x-K9
2800 wireless access point AIR-CAP2802I-x-K9
3.7 Setting Wireless Parameters of Patient Monitor
Configure the WLAN parameters of the patient monitor according to the table below:
Parameter Recommended Setting Description
Main Menu → Maintenance → User Maintenance → Network Setup → WLAN
SSID Actually used network
name
/
Safe mode WPA2-PSK It should be the same as the safe mode of the WLAN deployed for the patient monitor.
If EAP is used, select the safe mode according to the WLAN deployment.
Password Actually used network
password
/
Main Menu → Maintenance → User Maintenance → Network Setup → WLAN → WLAN Setup
WLAN band 5G Options: 2.4G, 5G and Auto
2.4G = Only the 2.4 GHz band is used.
5G = Only the 5 GHz band is used.
Auto = The 2.4 GHz and 5 GHz bands (5 GHz first) are used.
