4-1
4 Unpacking and Installation
4.1 Unpacking
Open the package and take out the packing list. Check that all the articles included on the packing list are available and
the quantity and specification are correct. Note that:
1. All the optional parts purchased by the customer shall also be checked.
2. Immediately contact the supplier if any item in the package is inconsistent with that listed on the packing list.
3. In case of damage during transportation, keep the packing material and immediately contact the supplier.
4. Keep the packing material until the product acceptance is completed.
4.2 Preparations for Installation
4.2.1 Installation Site Requirements
1. Ensure that the installation site meets all safety, environmental and power requirements.
2. Check that required power sockets are available.
3. Check whether a network connector is available if the monitor needs to connect to the wired network.
WARNING
When using the N1 Dock, use only the power cord supplied by the manufacturer to connect the AC power
supply. When using the monitor alone, use only the DC adapter supplied by the manufacturer to connect
the external power supply.
4.2.1.1 Environmental Requirements
To avoid explosion hazard, do not use the equipment in the presence of flammable anesthetics, vapors or liquids. To
avoid impact on thenormal operation, the monitor shall be placed in an environment free from vibration, dust and
corrosive substances.
Environmental specifications are as follows:
Main unit, adapter, and Transport Dock
Item Temperature (°C) Relative Humidity (Non-condensing) Atmospheric Pressure (kPa)
Working
environment
0~40 5%~95% 57.0~107.4
Storage and
transport
environment
–30~70 5%~95% 16.0–107.4 (without the CO
2
module)
50.0–107.4 (with the CO
2
module)
Microstream CO
2
module
Item Temperature (°C) Relative Humidity (Non-condensing) Atmospheric Pressure (kPa)
