BeneVision N1 - Page 72

7-2
3. Use three M2X4 cross recessed pan head screws to secure the Wi-Fi module to the main board.
4. Insert the antenna plug into the Wi-Fi receptacle as shown in the figure below. Make sure the outlet direction is
correct and the main board does not crush the antenna.
Wi-Fi module
Three M2X4 cross
recessed pan head
screws
Insert the antenna through the wire hole
on the main frame
