Benning ST 755+ - Table 30 Overview of Test Procedures According to en 50678 (VDE 0701) and en 50699 (VDE 0702) for Class I (1 to 16); Table 31 Overview of Test Procedures According to en 50678 (VDE 0701) and en 50699 (VDE 0702) for Class I (17 to 32); Table 34 Overview of Test Procedures According to en 50678 (VDE 0701) and en 50699 (VDE 0702) for

13.1 Automatic test procedures
Appendix
5284 / 08/2023 enBENNING ST 755+ / ST 760+104
Test/ test
no.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Visual
inspection
x x x x x x x x x x x x x x x x
Connection
test
x x x x x x x x x x x x x x x x
R
PE
600mA x - x - x x - x x x x x - x x -
R
PE
10A - x - - - - x - - - - - x - - -
R
Insu-1
/ R
Insu‑IN
x x x x x x x x - - x x x x x x
R
Insu-2
/ R
Insu‑IN
- - - - - - - - - - x - - - - -
R
Insu-3
- - - - - - - - - - x - - - - -
R
Insu-4
- - - - - - - - - - - - - - - -
I
PE
- - - - - x x - - - - x x - - -
I
Cont
- - x x - - - - - x x - - - - -
Funct. x x x x x - - x x x x - - - - -
Cable - - - - - - - - - - - - - x x x
U
a
- - - - - - - - - - x - - - - -
PRCD - - - - - - - - - - - - - - - -
Table30: Overview of test procedures according to EN50678 (VDE0701) and EN50699 (VDE0702) for
ClassI (1to 16)
Test/ test
no.
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Visual
inspection
x x x x x x x x x x x x x x x x
Connection
test
x x x x x x x x x x x x x x x x
R
PE
600mA x - x x x x x x - x x x x x x -
R
PE
10A - x - - - - - - - - - - - - - -
R
Insu-1
/ R
Insu‑IN
x x x x x x x x x x x x x x x x
R
Insu-2
/ R
Insu‑IN
- - x x - - x x x x x x x x x x
R
Insu-3
- - - - - - - - - - - - - - - -
R
Insu-4
- - - - - - - - - - - - - - - -
I
PE
- - x x - x x x x x x x x x x X
I
Cont
- - - - - - x - - - - - - - - -
Funct. x x - - x - - - - - - - - - - -
Cable - - - - - - - - - - - - - - - -
U
a
- - - - - - - - - - - - - - - -
PRCD - - x x - - x x x x x x x x x x
Table31: Overview of test procedures according to EN50678 (VDE0701) and EN50699 (VDE0702) for
ClassI (17to 32)
Testno. Name Individual tests
1 Devices of ClassII R
Insu-1
(500V), functional test with I
Cont
(differential current measuring method)
2 Devices of ClassII with I
Cont
alt. R
Insu-1
(500V), I
Cont
(alt.)
3 Devices of ClassII with R
Insu
250V R
Insu-1
(250V), functional test with I
Cont
(differential current measuring method)
4 Devices of ClassII without R
Insu
Functional test with I
Cont
(differential current
measuring method)
