7.6 Device information
Functions
5284 / 08/2023 enBENNING ST 755+ / ST 760+42
7.6 Device information
In the "Information" menu, you can find all current device data as well as contact data of the
Technical support [}page12].
• Device
• Item number
• Serial number
• Firmware version
• GUIversion
• Storage battery voltage/current
• Storage battery capacity
• Kernel version
• Technical support
– Phone number
– Faxnumber
– E-mail
– Website
7.7 Individual tests
7.7.1 Protective conductor resistance
EN50678 (VDE0701)
EN50699 (VDE0702)
EN62353
(VDE0751‑1)
EN60974-4
(VDE0544‑4)
ClassI ClassII ClassIII ClassI ClassII ClassI ClassII
X - - X - X -
Test samples with protective conductor must have a proper and safe connection to all
accessible conductive parts that are connected to the protective connector and can be live in
the event of a fault [}page79].
The protective conductor resistance is composed of the following values:
• The resistance value between the connection point of the test sample up to all accessible
conductive parts of the test sample that are connected to the protective conductor,
• The transition resistances of all terminal and plug connections,
• the resistances of all connected extension and device connecting cables.
To determine the protective conductor resistance, you can select various testing currents.
• Testing current: 0.6A‑AC or 10A‑AC
• Test frequency: 50Hz
When exceeding the limit [}page111], it has to be checked whether other limits have to be
observed due to product standards or manufacturer specifications.
