Patient monitor User’s manual
6
Touch screen
Touch screen input With
Others
Mouse input Support
A.5.7 Connectors
Power 1 AC power inlet
Wired network 1, standard RJ45 interfaces.100 BASE-TX, IEEE 802.3
USB 2, standard USB socket
(for the connections to a mouse,
U disk, and so on)
Video output 1 standard
VGA
connector
(PS: To get the equivalent of the same monitor LCD
display,Q7 should have vertical installation of the screen )
Auxiliary output
Defibrillation
synchronization
One standard BNC connector with software configuration
function for analog and synchronization output
Equipotential
grounding point
1
Nurse call 1 RJ11 connector for nurse call
SD card Optional
A.5.8 Signal Output
Auxiliary output interface
Standard IEC 60601-1 about short circuit protection and leakage
current request
Output impedance Rated 50Ω
ECG analog signals output
Bandwidth （-3dB
refer to 10Hz）
Diagnosis mode: 0.05 Hz to 120 Hz
Monitor mode: 0.5 Hz to 40Hz
Surgery mode: 1 Hz to 25Hz
Signal range -11V to +11V
