Possible signal sources for the inputs of instructions
2341 Actual position of table positioning
2351 … 2354 General source 1 … 4
Combination with constants
2380 … 2392 Auxiliary values (constants) and global flags (status signals)
Combination with digital global signal source of output buffer
2401 … 2416 Output buffer 1 … 16
Combination with analog output of an instruction
2501 … 2504 Outp. frequency 1 … 4
2511 … 2514 Outp. current 1 … 4
2521 … 2524 Outp. percent 1 … 4
2531 … 2534 Outp. voltage 1 … 4
2551 … 2554 Outp. user 1 … 4
2561 … 2564 Flag 1 … 4
Combination with fixed analog value
2601 … 2604 Fixed frequ. 1 … 4
2611 … 2614 Fixed current 1 … 4
2621 … 2624 Fixed perc. 1 … 4
2631 … 2634 Fixed eff. volt. 1 … 4
2641 … 2644 Fixed peak volt. 1 … 4
2651 … 2654 Fixed gen. 1 … 4
2661 … 2664 Fixed position 1 … 4
2671 … 2674 Fixed speed pos. 1 … 4
2681 … 2684 Fixed ramp pos. 1 … 4
2380 … 2392 – Auxiliary values (constants) and global flags (status signals)
2380 - "0.00 (zero percent)":
The auxiliary quantity has constant value 0%.
2381 - "100.00 (one hundred percent)":
The auxiliary quantity has constant value 100%
2382 - "327.67 (maximum value)":
The auxiliary quantity has constant value 327.67%
2383 - "0XFFF (for bitwise combination)":
The auxiliary quantity has constant hexadecimal value 0xFFFF and can be used for bitwise com-
binations.
2384 - "Fmax (100)":
Auxiliary quantity has constant value 100% of F
max
(of parameter Maximum frequency 419).
2385 - "Rated motor current in current data set":
The auxiliary quantity is referred to parameter value
Rated current 371 in the current data set.
The constant value is applied to the input of the instruction: 100% corresponds to the value of
the rated motor current.
2386 - "Short-time overload current (ILIMIT)":
The auxiliary quantity is referred to the type-dependent overload current. The constant value is
applied to the input of the instruction: 100% corresponds to the value of the overcurrent.
