Description Symbol Unit
HCS01.1E
-W0005-
_-03
HCS01.1E
-W0008-
_-03
HCS01.1E
-W0018-
_-03
HCS01.1E
-W0028-
_-03
HCS01.1E
-W0054-
_-03
Mains connection power at
U
LN_nenn
and P
DC_cont
(three-phase,
without mains choke)
S
LN
kVA 1.00 1.54 3.50 4.90 16.00
Mains connection power at
U
LN_nenn
and P
DC_cont
(three-phase,
with mains choke)
S
LN
kVA - tbd 5.50 18.00
Mains connection power at
U
LN_nenn
and P
DC_cont
(single-
phase, without mains choke)
S
LN
kVA -
Mains connection power at
U
LN_nenn
and P
DC_cont
(single-
phase, with mains choke)
S
LN
kVA -
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(single-phase, without
mains choke)
10)
TPF -
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(three-phase, without
mains choke)
11)
TPF 0.49 0.56 0.52 0.53 0.56
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(single-phase, with
mains choke)
12)
TPF -
Power factor TPF (λ
L
) at U
LN_nenn
and P
DC_cont
(three-phase, with
mains choke)
13)
TPF - tbd 0.72 0.78
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(single-phase,
without mains choke)
TPF
10%
-
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(three-phase,
without mains choke)
TPF
10%
0.30 0.35 0.38 0.40 0.45
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(single-phase,
with mains choke)
TPF
10%
-
Power factor TPF (λ
L
) at U
LN_nenn
and 10% P
DC_cont
(three-phase,
with mains choke)
TPF
10%
- tbd
Power factor of fundamental com‐
ponent DPF at P
DC_cont
(single-
phase, without mains choke)
cosφ
h1
-
Power factor of fundamental com‐
ponent DPF at P
DC_cont
(three-
phase, without mains choke)
cosφ
h1
0.99 0.98 0.99 0.98 0.97
Last modification: 2012-06-28
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P238/341
Rexroth IndraDrive CsDrive Systems with HCS01
Technical data of the components
