BL702/704/706 Reference Manual
Name
Description
qdec1_value QDEC1 value
qdec1_int_en QDEC1 interrupt enable
qdec1_int_sts QDEC1 interrupt status
qdec1_int_clr QDEC1 interrupt clear
qdec2_ctrl0 QDEC2 control0
qdec2_ctrl1 QDEC2 control1
qdec2_value QDEC2 value
qdec2_int_en QDEC2 interrupt enable
qdec2_int_sts QDEC2 interrupt status
qdec2_int_clr QDEC2 interrupt clear
14.4.1 qdec0_ctrl0
Address：0x4000a800
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
RSVD RPT
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
RPT SPL DEGCNT DEG
EN
LED
POL
LED
EN
QDEC
EN
Bits
Name Type Reset Description
31:28 RSVD
27:12 RPT R/W 16’d10 ”RPT” report period in [samples/report]. Specifies the num-
ber of samples to be accumulated in the ACC1 register be-
fore the RPT_RDY and DBL_RDY events can be generated
”RPT_US” report period in [us/report] = SP * RP
