Main Project Screen
Figure 5-18. Main Project Screen
1. Drop-down menus
2. Left Toolbar:
l Undo and Redo
l Zoom In and Out
l Add Fixtures
l Add Fixtures from Network
l Change Topology
l Record Preset
3. Source Previews
4. Processor Name/ Processor serial number
5. Right Toolbar:
l Canvas Mode
l Live Control On/Off
l Pause/Freeze
l Blackout
l Test Patterns
6. Property Tabs
7. Presets
8. The Canvas
