Brother MFC-J6510DW

3-120
Confidential
(3_090)
Paper feed motor harness
PF encoder disk
CR guide rail
PF sensor
harness
Registration
sensor harness
(Rear)
PF encoder
harness
PF encoder/
PF sensor
harness
(Left)
Lower cover
Lower cover
ASF motor harness
Carriage motor
harness
Main PCB
PF encoder/PF sensor
harness
Switchback paper
detection
sensor harness
Registration sensor
harness
Paper feed motor
harness
(Front)
Carriage motor harness
ASF encoder harness
Purge cam switch harness
Ink cartridge cover
switch harness
