 Paper jam on the manual feed slot (Error code 82, 83, 8A, 8B, 8C)
User Check
- Check whether recording paper is loaded correctly in the manual feed slot.
- Adjust the paper guide to match the recording paper size.
- Check whether two or more sheets of recording paper are loaded in the manual feed slot.
 Paper jam near the platen (Error code 84, 88, 8A, 8B, 8C)
User Check
- Adjust the paper guide to match the recording paper size.
- Check that the reccording paper weight is 75 to 105 g/m
2
.
Step Cause Solution
1 Foreign materials in the recording
paper path
Remove foreign materials.
2 Registration sensor actuator out of
place
Set the actuator into place.
3 Registration sensor harness
connection failure
Check the connection and reconnect the harness.
4 Paper feed motor harness
connection failure
Check the connection and reconnect the harness.
5
Paper feed motor defective
Replace the paper feed motor.
6 Registration sensor defective Replace the registration sensor PCB ASSY.
7 Paper feed roller does not rotate
Replace the engine unit.
8
Main PCB defective
Replace the main PCB ASSY.
Step Cause Solution
1
Foreign materials in the recording
paper path or around the
maintenance unit
Remove foreign materials.
2 Registration sensor actuator out of
place
Set the actuator into place.
3 Switchback paper detection
actuator out of place
Set the actuator into place.
4 Registration sensor harness
connection failure
Check the connection and reconnect the harness.
5
Switchback paper sensor harness
connection failure
Check the connection and reconnect the harness.
6 Registration sensor defective Replace the registration sensor PCB ASSY.
7 Switchback paper sensor
defective
Replace the switchback paper sensor PCB ASSY.
8
Engine unit defective Replace the engine unit.
9
Main PCB defective
Replace the main PCB ASSY.
