Brother MFC-J6920DW Service Manual

3-5
Confidential
4 SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening torque
N•m (kgf•cm)
ADF FG wire/FB FG wire TAPTITE CUP S M3x6 1 0.40±0.10 (4±1)
Document scanner unit TAPTITE BIND B M4x12 2 0.80±0.10 (8±1)
FB hinge TAPTITE BIND B M4x12 6 0.85±0.10 (8.5±1)
ADF unit TAPTITE BIND B M4x12 2 0.85±0.05 (8.5±0.5)
ADF hinge
TAPTITE CUP B M3x10 6 0.50±0.10 (5±1)
ADF reinforcement plate TAPTITE CUP B M3x10 1 0.50±0.10 (5±1)
Upper document chute TAPTITE CUP B M3x10 5 0.50±0.10 (5±1)
Document scanner base ASSY TAPTITE CUP B M3x10 5 0.55±0.05 (5.5±0.5)
Panel holder TAPTITE BIND B M4x12 3 0.70±0.10 (7±1)
Panel grounding wire TAPTITE CUP S M3x6 1 0.40±0.10 (4±1)
Panel lower cover TAPTITE CUP B M3x10 3 0.40±0.10 (4±1)
Upper cover TAPTITE BIND B M4x12 3 0.70±0.10 (7±1)
Main PCB shield TAPTITE CUP S M3x6 2 0.40±0.10 (4±1)
Main PCB ASSY TAPTITE CUP S M3x6 2 0.40±0.10 (4±1)
MJ upper frame TAPTITE CUP S M3x6 1 0.40±0.10 (4±1)
MJ PCB ASSY TAPTITE CUP S M3x6 1 0.40±0.10 (4±1)
Lower cover TAPTITE BIND B M4x12 4 0.70±0.10 (7±1)
Lower power supply frame TAPTITE CUP S M3x8 1 0.45±0.10 (4.5±1)
Power supply PCB ASSY TAPTITE CUP S M3x6 3 0.45±0.10 (4.5±1)
Engine FG wire TAPTITE CUP S M3x6 1 0.40±0.10 (4±1)
Main PCB frame TAPTITE CUP S M3x6 1 0.45±0.10 (4.5±1)
TAPTITE CUP B M3x10 2 0.40±0.10 (4±1)
CR frame ASSY TAPTITE CUP B M3x10 2 0.60±0.10 (6±1)
TAPTITE CUP S M3x6 1 0.40±0.10 (4±1)
SCREW BIND M3x6 2 0.60±0.10 (6±1)
Motor bracket SCREW BIND M3x6 2 0.60±0.10 (6±1)
Switchback frame TAPTITE CUP B M3x12 2 0.50±0.10 (5±1)
PF encoder sensor PCB ASSY SCREW BIND M2x12 1 0.15±0.05 (1.5±0.5)
CR guide rail SCREW BIND M3x6 2 0.60±0.10 (6±1)
TAPTITE CUP B M3x10 2 0.50±0.10 (5±1)
Paper feed motor frame ASSY SCREW BIND M3x6 2 0.60±0.10 (6±1)
Frame base TAPTITE CUP B M3x10 2 0.50±0.10 (5±1)
Engine FG wire TAPTITE CUP B M3x10 1 0.50±0.10 (5±1)
DX chute TAPTITE CUP B M3x10 2 0.50±0.10 (5±1)
Lower tray frame TAPTITE CUP B M3x8 2 0.50±0.10 (5±1)

Brother MFC-J6920DW Specifications

General

Type	all in one
Tray Capacity	500
Automatic Document Feeder Capacity	35 sheets
Paper Size	11" x 17"
Paper Handling	up to 500 sheets
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 6000 x 1200
Print Resolution Color	up to 6000 x 1200
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 2400 x 1200
Copier Resolution Color	up to 2400 x 1200
Fax Function	yes
Cartridges	lc103bk/c/m/y
Number Of Cartridges	4
Internal Memory	no
Memory Card	yes
Network	wireless
Connectivity	usb
OS Compatibility	pc: windows server 2003, server 2003 r2, server 2008, server 2008 r2, server 2012, xp home, xp professional, vista, 7 or 8, mac: os x v10.6x, 10.7x or 10.8x
Mobile Devices Connection	yes

Weight and Dimensions

Height	21.9 inches
Width	17 inches
Net Weight	36.4 pounds
