Brother MFC-J6920DW Service Manual

1-2
Confidential
1.3 Paper Handling
1.4 LCD Panel
1.5 Memory
1.6 Interface
Model MFC-J3520 MFC-J3720 MFC-J6520DW MFC-J6720DW MFC-J6920DW/J6925DW
Paper Input
(sheets)
Standard Tray 250 (80 g/m
2
)
Lower Tray
N/A 250 (80 g/m
2
) N/A 250 (80 g/m
2
)
Manual Feed Slot 1 (Plain: 120 g/m
2
, Grossy: 0.28 mm)
ADF 35 (80 g/m
2
)
Output Paper Capacity
(sheets)
50 (80 g/m
2
)
Model MFC-J3520 MFC-J3720 MFC-J6520DW MFC-J6720DW MFC-J6920DW/J6925DW
LCD
Type & Size 2.7 inch TFT 3.7 inch TFT
Touch-Panel Yes
Model MFC-J3520 MFC-J3720 MFC-J6520DW MFC-J6720DW MFC-J6920DW/J6925DW
Memory Capacity
(physical: Mbytes)
128 MB 256 MB
Memory Backup
(with Flash memory)
Yes
Model MFC-J3520 MFC-J3720 MFC-J6520DW MFC-J6720DW MFC-J6920DW/J6925DW
Host Interface Hi-Speed USB 2.0
LAN Yes
Wireless LAN Yes
NFC
N/A Yes
PictBridge Yes
USB Memory Yes
Acceptable Media Cards
(Type & Size)/Media Card
Memory Stick Duo: 16 MB-128 MB
Memory Stick Pro/Pro Duo/Micro: 256 MB-32 GB (MagicGate: YES if not use MG function)
SD Memory Card: 16 MB-2 GB (miniSD, miroSD with Adapter)
SDHC Memory Card: 4 GB-32 GB (miniSDHC, miroSDHC with Adapter)
SDXC Memory Card: 48 GB-128 GB
MultiMedia Card: 32 MB-2 GB
MultiMedia Card plus: 128 MB-4 GB
MultiMedia Card mobile: 64 MB-1 GB (with Adapter)

Brother MFC-J6920DW Specifications

General

Type	all in one
Tray Capacity	500
Automatic Document Feeder Capacity	35 sheets
Paper Size	11" x 17"
Paper Handling	up to 500 sheets
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 6000 x 1200
Print Resolution Color	up to 6000 x 1200
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 2400 x 1200
Copier Resolution Color	up to 2400 x 1200
Fax Function	yes
Cartridges	lc103bk/c/m/y
Number Of Cartridges	4
Internal Memory	no
Memory Card	yes
Network	wireless
Connectivity	usb
OS Compatibility	pc: windows server 2003, server 2003 r2, server 2008, server 2008 r2, server 2012, xp home, xp professional, vista, 7 or 8, mac: os x v10.6x, 10.7x or 10.8x
Mobile Devices Connection	yes

Weight and Dimensions

Height	21.9 inches
Width	17 inches
Net Weight	36.4 pounds
