2.3 Parts Names and Functions
Document scanning and feeding
Names Functions
Document detection actuator
This detects whether documents are set on the document tray.
Document width actuator This detects the width of the documents set on the document
tray.
Document pick-up roller
This pulls documents loaded in the document tray into the ADF.
Document separation roller/
ADF separation pad
This separates documents sent by the document pick-up roller
in single sheet.
Document feed roller1 This feeds a document to the second side CIS unit.
Document feed roller2 This feeds a document to the first side CIS unit.
Second side document
scanning position actuator
This detects the leading edge of document pages, indicating
the scanning start position of the second side.
(Only in the case of duplex scanning)
This detects paper jamming in the ADF.
First side document
scanning position actuator
This detects the leading edge of document pages, indicating
the scanning start position of the first side.
This detects paper jamming in the ADF.
Document ejection roller This ejects the document of which the first side is scanned to
document cover.
