Brother MFC-J6920DW Service Manual

1-5
Confidential
5 SCANNER
6 SOFTWARE
* Only MFC-J6925DW
7NETWORK
7.1 Network
7.2 Wired
7.3 Wireless
Model MFC-J3520 MFC-J3720 MFC-J6520DW MFC-J6720DW MFC-J6920DW/J6925DW
Scan speed
(Mono/Color) *@100 dpi
A4: 3.37 sec/3.48 sec
Letter: 3.17 sec/3.27 sec
Scan speed (Duplex)
(Mono/Color) *@100 dpi
N/A
A4:
3.37 sec/4.27 sec
Letter:
3.17 sec/4.01 sec
Resolution
(horizontal x
vertical)
Optical
FB: 2,400 x 2,400 dpi
ADF: 2,400 x 1,200 dpi
Interpolated For XP/Vista/Windows 7/Windows 8, Up to 19,200 x 19,200 dpi with Scanner Utility
Model All models
Driver Support
OS Version
Windows
Windows XP/XP x64/Vista/7/8/8.1*
Windows Server 2003/2003 R2/2008/2008 R2/2012/2012 R2*
Macintosh Mac OS X v10.6.8/10.7.x/10.8.x
Model All models
Internet FAX (Firmware)
(versionT37)
Yes (Download)
Model All models
Model Name (Ethernet) Embedded (NC-320h)
Network Connection (Ethernet) Ethernet 10/100BASE-TX Auto Negotiation
Model All models
Model Name (Wireless) Embedded (NC-330w)
Network Connection
(Wireless)
IEEE802.11 b/g/n
Wireless Security SSID (32 chr), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES)
Setup Support
Utility
AOSS Yes
WPS
(Wifi Protected
Setup)
Yes

Brother MFC-J6920DW Specifications

General

Type	all in one
Tray Capacity	500
Automatic Document Feeder Capacity	35 sheets
Paper Size	11" x 17"
Paper Handling	up to 500 sheets
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 6000 x 1200
Print Resolution Color	up to 6000 x 1200
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 2400 x 1200
Copier Resolution Color	up to 2400 x 1200
Fax Function	yes
Cartridges	lc103bk/c/m/y
Number Of Cartridges	4
Internal Memory	no
Memory Card	yes
Network	wireless
Connectivity	usb
OS Compatibility	pc: windows server 2003, server 2003 r2, server 2008, server 2008 r2, server 2012, xp home, xp professional, vista, 7 or 8, mac: os x v10.6x, 10.7x or 10.8x
Mobile Devices Connection	yes

Weight and Dimensions

Height	21.9 inches
Width	17 inches
Net Weight	36.4 pounds
