CHAPTER 1 SPECIFICATIONS
This chapter lists the specifications of each model, which enables you to make a comparison
of different models.
1GENERAL
1.1 General
1.2 Media Specification
* Only for Hong Kong/Taiwan/Korea
Model All models
Print Head BH13 BK/C/M/Y: 420/420/420/420 nozzles
Minimum Droplet Size
BK: 3 pl
CMY: 1.5 pl
Scanning Method CIS
CPU Speed 288 MHz
Backup Clock Yes (Up to 1 hour)
Model MFC-J3520 MFC-J3720 MFC-J6520DW MFC-J6720DW MFC-J6920DW/J6925DW
Media
Sizes
Standard Tray
<Landscape> A4, LTR, EXE,B5* <Portrait> A3, LGR, B4*, LGL, Folio, A5, A6,
Photo (102 x 152 mm/4 x 6"), Indexcard (127 x 203 mm/5 x 8"), Photo-L (89 x 127 mm/3.5 x 5"),
Photo-2L (127 x 178 mm/5 x 7"), C5, Com-10, DL Envelope, Monarch
Lower Tray
N/A
<Landscape>
A4, LTR
<Portrait>
A3, LGR,
B4*, LGL
N/A
<Landscape> A4, LTR
<Portrait> A3, LGR, LGL
Manual Feed Slot
<Landscape> A4, LTR, EXE, B5*
<Portrait> A3, LGR, B4*, LGL, Folio, A5, A6, Photo (102 x 152 mm/4 x 6"),
Indexcard (127 x 203 mm/5 x 8"), Photo-L (89 x 127 mm/3.5 x 5"),
Photo 2L (127 x 178 mm/5 x 7"), C5, Com-10, DL Envelope, Monarch
Duplex Print
<PC Print> A3, LGR, B4*, LGL, Folio, A4, LTR, EXE, A5, B5*
<Copy> A3, LGR, B4*, LGL, A4, LTR, A5
ADF (width/length) 148/148 mm to 297/431.8 mm (5.8/5.8" to 11.7/17.0")
Scanner Glass
(width/length)
Up to 297/431.8 mm (Up to 11.7/17.0")
Media
Weights
Standard Tray 64-220 g/m
2
(17-58 lb)
Lower Tray
N/A
64-105 g/m
2
(17-28 lb)
N/A 64-105 g/m
2
(17-28 lb)
Manual Feed Slot 64-220 g/m
2
(17-58 lb)
Duplex Print 64-105 g/m
2
(17-28lb)
ADF 64-90 g/m
2
(17-24lb)
Media
Types
Standard Tray Plain, Inkjet, Glossy (cast/resin), Transparency
Lower Tray
N/A Plain N/A Plain
Manual Feed Slot Plain, Inkjet, Glossy (cast/resin), Transparency, Envelope
Duplex Print Plain
ADF Plain

Brother MFC-J6920DW Specifications

General

Type	all in one
Tray Capacity	500
Automatic Document Feeder Capacity	35 sheets
Paper Size	11" x 17"
Paper Handling	up to 500 sheets
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 6000 x 1200
Print Resolution Color	up to 6000 x 1200
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 2400 x 1200
Copier Resolution Color	up to 2400 x 1200
Fax Function	yes
Cartridges	lc103bk/c/m/y
Number Of Cartridges	4
Internal Memory	no
Memory Card	yes
Network	wireless
Connectivity	usb
OS Compatibility	pc: windows server 2003, server 2003 r2, server 2008, server 2008 r2, server 2012, xp home, xp professional, vista, 7 or 8, mac: os x v10.6x, 10.7x or 10.8x
Mobile Devices Connection	yes

Weight and Dimensions

Height	21.9 inches
Width	17 inches
Net Weight	36.4 pounds
