Brother MFC-J6920DW Service Manual

3-71
Confidential
Assembling Note: Assemble a new First side CIS flat cable by bending the First side
CIS flat cable and affixing the Double-sided adhesive tape as
shown in the figure below.
Fig. 3-74
Double-sided
adhesive tape
Supporting tape
55±1
mm
(1.5mm)
(2 mm)
40±1
mm
25±1
mm
10±1
mm
356.6±2
mm
Term inal
Terminal
Supporting tape
45°±3.5°
(66 mm)
374 mm
45°±3.5°
248.4±2
mm
Double-sided adhesive tape
(1.5 mm)
(38
mm)
(1.5 mm)
(10 mm)
Double-sided
adhesive tape
24±1
mm
15±1
mm
To main body
To CIS unit
To main body
To CIS unit
Valley fold
Mountain fold
mm
1045±10

Brother MFC-J6920DW Specifications

General

Type	all in one
Tray Capacity	500
Automatic Document Feeder Capacity	35 sheets
Paper Size	11" x 17"
Paper Handling	up to 500 sheets
Color Print Speed	20 pages per minute
Mono Print Speed	22 pages per minute
Print Resolution Mono	up to 6000 x 1200
Print Resolution Color	up to 6000 x 1200
Scanner Type	flatbed
Scan Resolution	up to 2400 x 1200
Copier Resolution Mono	up to 2400 x 1200
Copier Resolution Color	up to 2400 x 1200
Fax Function	yes
Cartridges	lc103bk/c/m/y
Number Of Cartridges	4
Internal Memory	no
Memory Card	yes
Network	wireless
Connectivity	usb
OS Compatibility	pc: windows server 2003, server 2003 r2, server 2008, server 2008 r2, server 2012, xp home, xp professional, vista, 7 or 8, mac: os x v10.6x, 10.7x or 10.8x
Mobile Devices Connection	yes

Weight and Dimensions

Height	21.9 inches
Width	17 inches
Net Weight	36.4 pounds
