Purge types, ink usage, purge counts, and purge codes
The ink usage and purge count for COLOR are total values of three colors.
There is a mode in which color ink is consumed even though the black ink purge is
selected. Likewise, there is a mode in which black ink is consumed even though the
color ink purge is selected.
Purge Types Description
Ink Usage (ml) Purge Counts
Purge Codes
(to be entered
with
Maintenance
mode 76)
All
colors
Black
only
Color
only
All
colors
Black
only
Color
only
Normal purge
(NP)
Purge to be
performed by user
purge.
BLACK:
0.334
COLOR:
1.015
BLACK:
0.334
COLOR:
0
BLACK:
0
COLOR:
1.015
64 16 48 1
Periodical reset
purge (RP)
Purge to be
performed
periodically. The cycle
varies due to the
ambient temperature.
BLACK:
0.369
COLOR:
1.189
BLACK:
0.369
COLOR:
0.210
BLACK:
0.186
COLOR:
1.189
74 26 65 2
Power purge
(PP)
Purge to be
performed by user
purge.
BLACK:
0.580
COLOR:
2.264
BLACK:
0.580
COLOR:
0.210
BLACK:
0.186
COLOR:
2.264
132 36 113 3
Initial purge (uIP)
Purge to be
performed
automatically
immediately after the
user purchases the
machine.
BLACK:
4.374
COLOR:
16.000
--- --- 929 --- --- 4
User reset purge
(RP3)
Purge to be
performed by user
purge.
BLACK:
0.520
COLOR:
2.015
BLACK:
0.520
COLOR:
0.210
BLACK:
0.185
COLOR:
2.015
117 33 101 5
Engine setup
purge (eIP)
Purge to be
performed for refilling
the tubes with ink.
BLACK:
4.374
COLOR:
13.970
--- --- 832 --- --- 6
Periodic expelling
purge (RP2)
Purge to be
performed
periodically. The cycle
varies due to the
ambient temperature.
BLACK:
0.186
COLOR:
0.210
--- --- 17 --- --- 7
Periodic suction
purge (SP)
Purge to be
performed
periodically. The cycle
varies due to the
ambient temperature.
BLACK:
0.183
COLOR:
0.294
--- --- 22 --- --- 8
Small reset purge
(SRP)
Purge to be
performed
periodically. The cycle
varies due to the
ambient temperature.
BLACK:
0.369
COLOR:
0.504
BLACK:
0.369
COLOR:
0.210
BLACK:
0.186
COLOR:
0.504
40 26 31 9
Ink replacement
purge
(Not to be performed
by service personnel)
BLACK:
5.162
COLOR:
13.223
--- --- 294 --- --- 0
