BRP ROTAX 916 i A Series Installation Manual

BRP-Rotax
INSTALLATION MANUAL
The Display CAN is based on the CAN Aerospace protocol. For detailed interface descrip-
tion contact an authorized ROTAX® Distributor or its independent Service Center.
Electromagnetic
shielding of CAN
Bus
The electromagnetic CAN Bus shielding ring terminals need to be connected with the Air-
frame Ground.
Connector: Ring Terminal M6
77–00–00
Page 12
December 01 2023
Effectivity: 916 i A / C24
Edition 0/Rev. 1
