INSTALLATION MANUAL
Weight
Engine component Weight
Base engine with gearbox: 75.44 kg (166.3 lb)
Governor drive add on weight version 3 0.60 kg (1.32 lb)
Cooling air baffle 0.38 kg (0.838 lb)
PCV 0.35 kg (0.771 lb)
Oil tank 1.50 kg (3.30 lb)
Intercooler
1.65 kg (3.65 lb)
ECU 1.13 kg (2.49 lb)
Fusebox 916 I A Series 2.02 kg (4.45 lb)
Fusebox 916 I C24 Series 1.84 kg (4.06 lb)
Ambient sensors
0.06 kg (0.132 lb)
Wiring harness 916 I A Series 2.50 kg (5.51 lb)
Wiring harness 916 I C24 Series 1.84 kg (4.06 lb)
Intermediate flange with overboost valve, air hose
and clamps
0.78 kg (1.72 lb)
AD-DC Converter assy. 1.68 kg (3.70 lb)
Starter Relay 0.14 kg (0.308 lb)
Effectivity: 916 i A / C24
Edition 0/Rev. 1
72–00–00
Page 11
December 01 2023
