B-2 Appendix B: Wiring
HOME
Speed sensor Under seat, to right of shock 3 [65]
B.9 DEUTSCH and B.4
DEUTSCH STANDARD
TERMINAL
Speedometer/indicators On back of speedometer 12 [39] Packard
Starter Under starter solenoid 1 [128] blade-type
System relay Under seat, to left of battery 4-blade [171] relay
Tail lamp/rear directionals Under Seat 6 [7] B.2 AMP MULTILOCK
Throttle position sensor and auto-
enrichener
Under frame backbone, right
side
6[88]
B.9 DEUTSCH and B.4
DEUTSCH STANDARD
TERMINAL
Voltage regulator Above swingarm, left side 2 [46] barrel
Table B-1. Electrical Connectors: 2007 Blast P3 Model
COMPONENT(S) LOCATION PLACE NO. REPAIR INSTRUCTIONS
