111
6. SYMBOLOGIES
6-4-4 Code 39 Message Length
Scan the barcodes below to change the message length. Refer to Message
Length Description for additional information. Minimum and Maximum lengths
= 0-48.
Minimum Default = 0 Maximum Default = 48
Minimum Message Length
Maximum Message Length
6-4-5 Code 39 Append
This function allows the scanner to append the data from several Code 39 bar
codes together before transmitting them to the host computer. When the
scanner encounters a Code 39 bar code with the append trigger character(s),
it buffers Code 39 bar codes until it reads a Code 39 bar code that does not
have the append trigger. The data is then transmitted in the order in which the
bar codes were read (FIFO). Default = Off
On
Off
