5-4 Data Format Editor Commands
When working with the Data Format Editor, a virtual cursor is moved along
your input data string. The following commands are used to both move this
cursor to different positions, and to select, replace, and insert data into the final
output.
5-4-1 Send Commands
F1-Send all characters
Include in the output message all of the characters from the input message,
starting from current cursor position, followed by an insert character. Syntax =
F1xx where xx stands for the insert character’s hex value for its ASCII code.
Refer to the ASCII Conversion Chart, for decimal, hex and character codes.
F2-Send a number of characters
Include in the output message a number of characters followed by an insert
character. Start from the current cursor position and continue for “nn”
characters or through the last character in the input message, followed by
character “xx.” Syntax = F2nnxx where nn stands for the numeric value (00-99)
for the number of characters, and xx stands for the insert character’s hex value
for its ASCII code. Refer to the ASCII Conversion Chart, for decimal, hex and
character codes.
