Canon imagePROGRAF iPF810 User Manual

v��� Contents
Contents
Adjustments for Better Print Quality 553
Adjust�ng the Pr�nthead .................................................................................553
Adjust�ng the Pr�nthead ...........................................................................................................553
Automat�c Stra�ghten�ng of L�nes and Colors (Auto Head Adj.) ...............................................554
Manual Stra�ghten�ng of L�nes and Colors (Manual Head Adj) ................................................556
Adjust�ng L�ne M�sal�gnment (Head Inc. Adj.) ..........................................................................558
Troubleshoot�ng Paper Abras�on and Blurry Images (Head He�ght) ........................................561
Adjust�ng the feed amount ............................................................................562
Adjust�ng the Feed Amount .....................................................................................................562
Select�ng a Feed Amount Adjustment Method (Feed Pr�or�ty) .................................................563
Auto Band Adjustment (Auto Band Adj.) ..................................................................................564
Manual Band Adjustment (Manual Band Adj) ..........................................................................566
Band�ng Adjustment Dur�ng Pr�nt�ng (F�ne Band Adj.) .............................................................568
Adjust�ng L�ne Length (Adjust Length) ....................................................................................569
Adjust�ng the Vacuum Strength (VacuumStrngth) ...................................................................571
Maintenance 572
Ink Tanks .......................................................................................................572
Ink Tanks .................................................................................................................................572
Replac�ng Ink Tanks ................................................................................................................573
Check�ng Ink Tank Levels ........................................................................................................584
When to Replace Ink Tanks .....................................................................................................585
Pr�ntheads .....................................................................................................586
Pr�nthead .................................................................................................................................586
Check�ng for Nozzle Clogg�ng .................................................................................................587
Clean�ng the Pr�nthead ............................................................................................................588
Replac�ng the Pr�nthead ..........................................................................................................589
Ma�ntenance Cartr�dge .................................................................................595
Ma�ntenance Cartr�dge ............................................................................................................595
Replac�ng the Ma�ntenance Cartr�dge .....................................................................................595
Check�ng the Rema�n�ng Ma�ntenance Cartr�dge Capac�ty .....................................................603
When to Replace the Ma�ntenance Cartr�dge .........................................................................604
Clean�ng the Pr�nter ......................................................................................605
Clean�ng the Pr�nter Exter�or ...................................................................................................605
Clean�ng Ins�de the Top Cover ................................................................................................606
Clean�ng the Pr�nthead ............................................................................................................609
Other Ma�ntenance .......................................................................................610
Prepar�ng to Transfer the Pr�nter .............................................................................................610
Updat�ng the F�rmware ............................................................................................................615

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
