Page #684 background image
Messages regarding paper
Borderless printng not possible.
Lift release lever and reload the paper .
Cause Corrective Action
Because paper expands or contracts depending on
the environment of use, it may become narrower or
wider than the supported width for borderless printing.
Hold down the Stop button for a second or more to
cancel printing.
Use each type of paper only where the recommended
environmental conditions are met. For details on
environmental conditions for various paper , see the
Paper Reference Guide .
( P .125)
Lift the Release Lever and straighten the paper so
that the edge of the paper is in the width of the ink
groove for borderless printing.
Insert the roll rmly until it touches the ange of the
Roll Holder .
( P .136)
The paper is loaded askew .
If you press the Online button and continue printing,
the document will be printed with a border .
Check supported paper .
Cause Corrective Action
Follow these steps to change the settings of the print
job to enable borderless printing.
1. Hold down the Stop button for a second or more
to cancel printing.
2. Make sure the correct printer driver for the printer
is selected and try printing again.
For information on types of paper compatible with
borderless printing, refer to the Paper Reference
Guide .
( P .125)
The print job received species a type or width of
paper that is not compatible with borderless printing.
If you press the Online button and continue printing,
the document will be printed with a border .
Hold down the Stop button for a second or more to
cancel printing.
The loaded paper is not compatible with borderless
printing.
If you press the Online button and continue printing,
the document will be printed with a border .
670 Error Message

Table of Contents

Other manuals for Canon imagePROGRAF iPF810

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF810 and is the answer not in the manual?

Canon imagePROGRAF iPF810 Specifications

Print Specifications IconPrint Specifications
print resolution2400 x 1200 dpi
line accuracy±0.1% or Less
minimum line weight0.02 mm
number of nozzles (Matte Black)5, 120 Nozzles
number of nozzles (Other Colors)2, 560 Nozzles per Color
droplet size4 Picoliter
nozzle pitch (head resolution)1200 dpi x Two Rows
print-head swath1.07 inch
Ink and Media IconInk and Media
ink type (Dye)Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)Matte Black (MBK)
ink tank shipped with printerPFI-303 (330ml) MBK, C, M, Y, K
ink tank replacementPFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)10" – 44" (254mm – 1118mm)
media width (Cut Sheet)8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)59' (18m)
maximum print length (Cut Sheet)63" (1.6m)
media thickness0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter5.9" (150mm)
Power and Noise IconPower and Noise
power supplyAC 100–240V (50-60Hz)
power consumption (Maximum)190W or Less
power consumption (Standby)6W or Less
acoustic noise (Operation)52dB (A) or Less
acoustic noise (Standby)35dB (A) or Less
acoustic power6.8 Bels or Less
Operating Environment IconOperating Environment
temperature59 – 86 F° (15 – 30 C°)
relative humidity10 – 80% (No Condensation)
Weight and Dimensions IconWeight and Dimensions
printer dimensions (iPF810/iPF810 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)Approx. 768 lb. (348kg)
