Handling sheets for paper feed slots
Clearing a Jammed Sheet
If a sheet jams, follow the steps below to remove it.
Caution
• Remove any jammed paper promptly .
1. T urn the printer of f. ( → P .29)
2. Open the T op Cover .
3. If the Carriage is out, move the Carriage out of the way , away from the paper .
Important
• Do not touch the Linear Scale (a), Carriage Shaft (b), or Ink T ube Stabilizer (c). T ouching these
parts may damage them.
4. Lift the Release Lever .
170 Handling Paper
To Next Page
