Printer Driver
Main Pane (Mac OS X)
The following settings are available on the Main pane. For details on settings items, refer to the printer
driver help le.
Note
On the Main pane, choose Easy Settings to specify basic print settings based on the printing
application, or switch to Advanced Settings to complete more detailed settings as desired.
Conguration using Easy Settings
Setting Item Description
A Media T ype
Select the type of paper .
For information on the types of paper the printer supports, refer to the Paper
Reference Guide . ( P .125)
B Get Information Click to display the Get Information dialog box, which shows the types of
paper specied on the printer for each feed source. When you select a
feed source, your selection is applied to the printer driver settings for the
feed source and type of paper .
C Set
Click to display the Paper Detailed Settings dialog box for ink drying time
and other detailed settings based on the type of paper .
E Print T arget Choose presets that match the type of document to be printed.
Printing Photos and Images (→P .172)
Printing Line Drawings and T ext (→P .185)
Printing Of ce Documents (→P .202)
F V iew set. Click to display the V iew settings dialog box, which enables you to conrm
the settings for the selected item from the E Print T arget list or change the
order of items listed in E Print T arget .
L Printer Click to display the Printer dialog box, which indicates the ink levels and
gives other information about the printer .
436 Mac OS X Software

Table of Contents

Other manuals for Canon imagePROGRAF iPF810

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF810 and is the answer not in the manual?

Canon imagePROGRAF iPF810 Specifications

Print Specifications IconPrint Specifications
print resolution2400 x 1200 dpi
line accuracy±0.1% or Less
minimum line weight0.02 mm
number of nozzles (Matte Black)5, 120 Nozzles
number of nozzles (Other Colors)2, 560 Nozzles per Color
droplet size4 Picoliter
nozzle pitch (head resolution)1200 dpi x Two Rows
print-head swath1.07 inch
Ink and Media IconInk and Media
ink type (Dye)Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)Matte Black (MBK)
ink tank shipped with printerPFI-303 (330ml) MBK, C, M, Y, K
ink tank replacementPFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)10" – 44" (254mm – 1118mm)
media width (Cut Sheet)8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)59' (18m)
maximum print length (Cut Sheet)63" (1.6m)
media thickness0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter5.9" (150mm)
Power and Noise IconPower and Noise
power supplyAC 100–240V (50-60Hz)
power consumption (Maximum)190W or Less
power consumption (Standby)6W or Less
acoustic noise (Operation)52dB (A) or Less
acoustic noise (Standby)35dB (A) or Less
acoustic power6.8 Bels or Less
Operating Environment IconOperating Environment
temperature59 – 86 F° (15 – 30 C°)
relative humidity10 – 80% (No Condensation)
Weight and Dimensions IconWeight and Dimensions
printer dimensions (iPF810/iPF810 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)Approx. 768 lb. (348kg)
