Page #245 background imageLoading...
Page #245 background image
Choosing Paper for Printing
Choosing Paper for Printing
Choosing a Paper for Printing
Choosing the right paper for your particular printing application will give you the best printing results.
Media type
The printer and printer driver of fer print settings optimized for various paper characteristics.
Note
For information on the types of paper the printer supports, refer to the Paper Reference Guide . ( P .125)
The paper type setting in the printer driver and related software (as well as on the Control Panel ) is
updated when you install the Media Conguration T ool from the User Software CD-ROM or if you change
paper information by using the Media Conguration T ool . For information about the Media Conguration
T ool , see the Media Conguration T ool Guide (Windows) or Media Conguration T ool Guide (Macintosh).
An error message is displayed on the printer Control Panel if the paper type as specied in the printer
driver does not match the type specied on the printer . Although you can print under these conditions,
the printing results may not be suitable.
If the paper type is not listed for selection
If the type of paper loaded cannot be selected, try specifying glossy paper or proong paper as a special
paper (Special 1 to Special 5, in this order). BK ( Black Ink ) is used as the black ink. T ry specifying other
types of paper as Special 6 to Special 10. MBK ( Matte Black Ink ) is used as the black ink. Note that higher
numbers in this setting enable more vivid colors but may also cause colors to run together .
For instructions on specifying the paper type before printing, refer to the following topics.
Selecting the Paper T ype (Roll) (→P .134)
Selecting the Paper T ype (Sheet) (→P .163)
Enhanced Printing Options 231

Table of Contents

Other manuals for Canon imagePROGRAF iPF810

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF810 and is the answer not in the manual?

Canon imagePROGRAF iPF810 Specifications

Print Specifications IconPrint Specifications
print resolution2400 x 1200 dpi
line accuracy±0.1% or Less
minimum line weight0.02 mm
number of nozzles (Matte Black)5, 120 Nozzles
number of nozzles (Other Colors)2, 560 Nozzles per Color
droplet size4 Picoliter
nozzle pitch (head resolution)1200 dpi x Two Rows
print-head swath1.07 inch
Ink and Media IconInk and Media
ink type (Dye)Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)Matte Black (MBK)
ink tank shipped with printerPFI-303 (330ml) MBK, C, M, Y, K
ink tank replacementPFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)10" – 44" (254mm – 1118mm)
media width (Cut Sheet)8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)59' (18m)
maximum print length (Cut Sheet)63" (1.6m)
media thickness0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter5.9" (150mm)
Power and Noise IconPower and Noise
power supplyAC 100–240V (50-60Hz)
power consumption (Maximum)190W or Less
power consumption (Standby)6W or Less
acoustic noise (Operation)52dB (A) or Less
acoustic noise (Standby)35dB (A) or Less
acoustic power6.8 Bels or Less
Operating Environment IconOperating Environment
temperature59 – 86 F° (15 – 30 C°)
relative humidity10 – 80% (No Condensation)
Weight and Dimensions IconWeight and Dimensions
printer dimensions (iPF810/iPF810 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)Approx. 768 lb. (348kg)
