Canon imagePROGRAF iPF810 User Manual

Installation problems
Removing Installed Printer Drivers
Follow these steps to remove installed printer drivers and utilities.
Removing printer drivers (W indows)
Remove the printer driver as follows.
Note
• In Windows 2000/Windows XP/Windows Server 2003/Windows V ista/Windows Server 2008, you must
log on with administrative rights, such as those of the “Administrator” account.
1. From the Windows start menu, select Programs > Canon Printer Uninstaller >
imagePROGRAF Printer Driver Uninstaller to display the Delete Printer window .
2. Select the printer in the list and click Delete .
3. Click Y es after the W arning message is displayed.
4. Make sure that the printer has been removed from the list, and then click Exit .
Removing printer drivers and imagePROGRAF Printmonitor
(Macintosh)
Remove the printer driver or imagePROGRAF Printmonitor as follows.
1. Insert the User Software CD-ROM provided with the printer in the CD-ROM drive.
2. Start the printer driver installer included in the User Software CD-ROM .
Open the OS X folder and double-click iPF Driver Installer X .
3. In the upper left menu, choose Uninstall , and then click Uninstall .
4. Follow the instructions on the screen to remove the printer driver or imagePROGRAF
Printmonitor .
Removing imagePROGRAF Status Monitor (W indows)
Remove imagePROGRAF Status Monitor as follows.
1. From the Windows start menu, select Programs > imagePROGRAF Status Monitor >
Uninstaller (imagePROGRAF Status Monitor) to start the wizard.
2. In the wizard window , click Delete , and then click Next .
3. Follow the instructions on the screen to remove imagePROGRAF Status Monitor .
Removing imagePROGRAF Device Setup Utility (W indows)
Remove imagePROGRAF Device Setup Utility as follows.
1. From the Windows start menu, select Programs > imagePROGRAF Device Setup Utility >
Uninstaller (imagePROGRAF Device Setup Utility) to start the wizard.
2. In the wizard window , click Delete , and then click Next .
3. Follow the instructions on the screen to remove imagePROGRAF Device Setup Utility .
T roubleshooting 649

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
