Canon imagePROGRAF iPF810 User Manual

Printer Driver
ICC Matching Mode , Driver ICM Mode and Host ICM Mode
On the Matching sheet, you can specify color matching to compensate for dif ferences in the appearance of
colors on various devices. The following options are available when you select ICC Matching Mode , Driver
ICM Mode , or Host ICM Mode on the Matching Mode sheet.
Note
• T o display the Matching sheet, on the Main sheet, click Color Settings by Color Mode in Advanced
Settings , and then click the Matching sheet. ( → P .395)
Setting Item Description
A Matching Mode
Select the color matching mode to use, as desired.
B Input Prole Settings Y ou can select Image , Graphics , or T ext . Y ou can
choose Matching Method and Input Prole .
V arious options are available depending on your
selected Matching Mode .
T o apply the same input prole automatically for
Graphics and T ext , select Use the Same Prole
for All Objects . T o apply separate input proles to
Graphics and T ext , clear Use the Same Prole for
All Objects and specify the individual settings.
C Printer Prole Settings
Specify the printer prole as desired. Normally , select
Auto Settings .
Note
• For details on settings items, see “Adjusting the Color in the Printer Driver”. (→P .212)
404 Windows Software

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
