Printing CAD Drawings
Printing CAD Drawings in Monochrome
The following settings are available for monochrome printing of line drawings such as CAD documents.
Easy
Settings
Print
T arget
CAD
(Monochrome
Line Drawing )
Settings optimized for monochrome printing of line
drawings, such as CAD drawings. When you select
Easy Settings > Print T arget > CAD (Monochrome
Line Drawing ) , color is printed as shades of gray
using black ink, for monochrome printing.
• This mode may not be available for all types of
paper .
• T race amounts of color ink are also used, to
enhance the paper adhesion of black ink.
Printing Line Drawings and T ext (Windows) (→P .187)
Printing Line Drawings and T ext (Mac OS X)
(→P .189)
Monochrome
(BK ink)
Monochrome printing, using black ink. Color
is printed in grayscale. Use this mode when
printing CAD drawings or similar line drawings in
monochrome.
• This mode may not be available for all types of
paper .
• T race amounts of color ink are also used, to
enhance the paper adhesion of black ink.
Fine-T uning Monochrome Settings When Printing
Line Drawings (Windows) (→P .193)
Fine-T uning Monochrome Settings When Printing
Line Drawings (Mac OS X) (→P .195)
Main
Advanced
Settings
Color
Mode
Monochrome
Bitmap
All colors except white are printed in black. Colors
are shown not in grayscale but solid black. Use
this mode to print documents with ne color lines
that might be dif cult to distinguish unless printed
in black, or to print sharp black lines when making
copies of diazo prints.
• This mode may not be available for all types of
paper .
• T race amounts of color ink are also used, to
enhance the paper adhesion of black ink.
192 W orking With V arious Print Jobs
