Canon imagePROGRAF iPF810 User Manual

Hard Disk
Erasing Data on the Printer ’ s Hard Disk
Y ou can erase data on the printer ’ s hard disk from the Control Panel .
There are three ways to erase the data, as follows.
Erasure Method
T ime Required
Details
High Speed A few seconds Erases le management data for print job data stored on the
printer ’ s hard disk. Choose this method for relatively fast
erasure. Because only the le management data is erased, the
print job data itself is not erased. Note that it may be possible to
read this data using commercial data recovery software.
Secure High Spd. About 40 minutes Overwrites the entire hard disk with random data. No verication
is performed to check if the data was correctly written. Choose
this method to erase highly condential data. Note that it may
be possible to read the overwritten data using specialized data
recovery tools.
Secure About 24 hours Overwrites the entire hard disk with 00, FF , and random data
(one time each). V erication is performed to check if the data
was correctly written. Choose this method to erase especially
condential data. It is virtually impossible to recover the
overwritten data. Conforms to the DoD5220.22-M standard of
the U.S. Department of Defense.
Note
• For a more secure method of preventing data recovery , we recommend physically or magnetically
destroying the hard disk. In this case, the hard disk can no longer be used.
• Y ou cannot erase data on the hard disk during print jobs.
• Conversely , print jobs cannot be processed during erasure of hard disk data.
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select System Setup , and then press the ► button.
3. Press ▲ or ▼ to select Erase HDD Data , and then press the ► button.
4. Press ▲ or ▼ to select the method of erasure, and then press the ► button.
5. Press ▲ or ▼ to select Y es , and then press the OK button to display the conrmation screen.
6. Press ▲ or ▼ to select Y es , and then press the OK button to start erasure.
552 Hard Disk

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
