Canon imagePROGRAF iPF810 User Manual

Responding to Messages
Error Messages
Error messages
Check the message and take the appropriate action.
• Before borderless printing, move the blue platen switch. (→P .675)
• Blue platen switch is dirty . (→P .676)
• Borderless printng not possible. (→P .670)
• Borderless printng not possible. Paper stretched or shrank. (→P .675)
• Cannot adjust band. (→P .674)
• Cannot adjust printhead. (→P .675)
• Cannot print as specied. (→P .674)
• Close Ink T ank Cover (→P .671)
• End of paper feed. (→P .668)
• ERROR Exxx-xxxx (x represents a letter or number) (→P .683)
• File read error . (→P .680)
• GARO Wxxxx (x represents a number) (→P .683)
• GL2: W0502 The parameter is out of range. (→P .682)
• GL2: W0504 This command is not supported. (→P .682)
• GL2: Wxxxx The memory is full. (xxxx is 0501, 0903, or 0904) (→P .682)
• Hard disk error . (→P .680)
• Hardware error . xxxxxxxx-xxxx (x represents a letter or number) (→P .683)
• Ink insufcient. (→P .671)
• No ink left. (→P .671)
• Ink tank is empty . (→P .672)
• Insert the maintenance cartridge. (→P .679)
• Insufcient paper for job (→P .663)
• Mail box full. Now printing without saving data. (→P .680)
• Mail box nearly full. (→P .680)
• Maintenance cartridge full. (→P .679)
• Maintenance cartridge problem. (→P .679)
• Maximum jobs stored. (→P .681)
• Media take-up unit ready . (→P .669)
• Multi-sensor error (→P .684)
• No ink tank loaded. (→P .672)
• No Maintenance Cartridge capacity . (→P .679)
• No printhead (→P .678)
• Not much ink is left. (→P .672)
• Paper cutting failed. (→P .668)
• Paper jam. (→P .666)
• Paper loaded askew . (→P .667)
• Paper size not detected. (→P .662)
• Papr T ype Mismatch (→P .660)
• PaprT ypeMismatch (→P .660)
• Parts replacement time has passed. (→P .684)
• PHead needs cleaning. (→P .678)
• Prepare for maint cart replacement. (→P .679)
• Prepare for parts replacement. (→P .684)
• Printhead error (→P .678)
658 Error Message

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
