Printer parts
Using the Stationary Output Stacker
The Stationary Output Stacker can be used in three positions, as shown.
• When storing printed documents on the Output Stacker
Use position (1).
• When the Output Stacker is not used
Move the stacker into position (2).
• When the Media T ake-up Unit is used, or when the Output Stacker is stored for long periods
Lower it to position (3) for storage. ( → P .23)
When using the Output Stacker again after storage, reattach the Basket Rod on the front of the Output
Stacker to the tips of the left and right basket arms and pull the side rods out completely .
• When printing on large, stif f sheets
Use position (3).
Important
• When storing printed documents on the Output Stacker , always use it in position (1). If you do not, printed
documents may not be dropped into the Output Stacker , and the printed surface may become soiled.
• The Output Stacker can accommodate one sheet. When printing multiple pages, remove each sheet
after it is printed.
• Before using the Output Stacker , remove the Rewind Spool . If you do not, it may prevent printed
documents from being held correctly , and they may be scratched.
• The Output Stacker can hold printed documents from rolls that are 62 inches (1,575 mm) long. When
printing longer documents, use the optional Media T ake-up Unit .
Printer Parts 21
