Canon imagePROGRAF iPF810 User Manual

Control Panel
Interface Setup
Setting Item Description, Instructions
EOP T imer Specify the timeout period before cancellation of
print jobs that cannot be received by the printer .
IP Mode Choose whether the printer IP address is
congured automatically or a static IP address
is entered manually .
DHCP
BOOTP
Protocol
RARP
Specify the protocol used to congure the IP
address automatically .
IP Address
Subnet Mask
TCP/IP
IP Setting
Default G/W
Specify the printer network information when
using a static IP address.
Enter the IP address assigned to the printer , as
well as the network subnet mask and default
gateway .
NetW are Specify the NetW are protocol. T o apply your
changes, choose Register Setting .
Frame T ype Specify the frame type to use.
NetW are
Print Service Choose the print service.
AppleT alk Specify whether to use the AppleT alk protocol.
T o apply your changes, choose Register
Setting .
Auto Detect Specify the communication method. T o apply
your changes, choose Register Setting .
Choose On for automatic conguration of the
LAN communication protocol. Choose Off
to apply Comm.Mode and Ethernet T ype
settings.
Comm.Mode Choose the LAN communication method.
Ethernet T ype Choose the LAN transfer rate.
Spanning T ree Choose whether spanning-tree packets are
supported over the LAN.
Ethernet Driver
MAC Address Displays the MAC address.
Ext. Interface Specify whether or not to use the optional
expansion interface when it is installed.
Return
Defaults
Return Defaults/Execute? is displayed if you
press the ▼ button. Choose OK to restore the
network settings to the default values.
Printer Parts 65

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
