Canon imagePROGRAF iPF810 User Manual

v� Contents
Contents
Ut�l�ty Sheet (W�ndows) ...........................................................................................................416
Support Sheet (W�ndows) .......................................................................................................417
Dev�ce Sett�ngs Sheet (W�ndows) ...........................................................................................418
Sett�ngs Summar�es D�alog Box (W�ndows) ............................................................................419
Status Mon�tor ...............................................................................................420
�magePROGRAF Status Mon�tor (W�ndows) ...........................................................................420
D�g�tal Photo Front-Access ...........................................................................421
D�g�tal Photo Front-Access ......................................................................................................421
PosterArt�st ...................................................................................................422
Us�ng PosterArt�st to Compose Or�g�nals ................................................................................422
Us�ng PosterArt�st to Compose Or�g�nals (W�ndows) ..............................................................423
Dev�ce Setup Ut�l�ty .......................................................................................425
�magePROGRAF Dev�ce Setup Ut�l�ty .....................................................................................425
Install�ng �magePROGRAF Dev�ce Setup Ut�l�ty .....................................................................426
Conguring the IP Address Using imagePROGRAF Device Setup Utility ...............................427
Mac OS X Software 428
Pr�nter Dr�ver .................................................................................................428
Pr�nter Dr�ver Sett�ngs (Mac OS X) .........................................................................................428
Spec�fy�ng Paper �n the Pr�nter Dr�ver (Mac OS X) .................................................................429
Conrming Print Settings (Mac OS X) .....................................................................................431
Check�ng the Layout �n a Prev�ew Before Pr�nt�ng (Mac OS X) ..............................................433
Us�ng Favor�tes (Mac OS X) ....................................................................................................434
Access�ng the Pr�nter Dr�ver D�alog Box from Appl�cat�ons (Mac OS X) .................................435
Ma�n Pane (Mac OS X) ...........................................................................................................436
Paper Informat�on on Pr�nter D�alog Box (Mac OS X) .............................................................439
Med�a Deta�led Sett�ngs D�alog Box (Mac OS X) ....................................................................440
V�ew Sett�ngs D�alog Box for the Pr�nt�ng Appl�cat�on (Mac OS X) ..........................................441
Color Sett�ngs Pane: Color (Mac OS X) ..................................................................................442
Color Sett�ngs Pane: Monochrome (Mac OS X) ......................................................................444
Page Setup Pane (Mac OS X) ................................................................................................445
Ut�l�ty Pane (Mac OS X) ..........................................................................................................447
Add�t�onal Sett�ngs Pane (Mac OS X) .....................................................................................448
Support Pane (Mac OS X) .......................................................................................................449
Pr�ntmon�tor ..................................................................................................450
�magePROGRAF Pr�ntmon�tor (Mac�ntosh) .............................................................................450
Network Setting 451
Network Sett�ng ............................................................................................451
Network Env�ronment ..............................................................................................................451
Conguring the IP Address on the Printer ...............................................................................453
Conguring the IP Address Using imagePROGRAF Device Setup Utility ...............................454
Conguring the IP Address Using the Printer Control Panel ...................................................455
Conguring the IP Address Using ARP and PING Commands ...............................................456
Us�ng RemoteUI ......................................................................................................................457

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
