Canon imagePROGRAF iPF810 User Manual

Printer Driver
Favorites Sheet (W indows)
The following settings are available on the Favorites sheet. For details on settings items, refer to the printer
driver help.
Setting Item Description
A Favorites
Printing favorites you have created are listed with Default Settings
favorites.
Using Favorites (→P .372)
B Settings Details
Displays details of the favorite selected in the A Favorites .
C Comment
Displays notes registered in the favorite.
D Apply Favorite Click to change the current print settings to those of the favorite
selected in the A Favorites .
E Application Settings Priority Activate this setting to use settings values specied in the source
application in preference to favorite settings selected in the A
Favorites , when clicking D Apply Favorite . For details on the settings
items used in preference, refer to the printer driver help.
F Delete
Click to delete the selected favorite from the A Favorites list.
G Edit
Click to display the Edit dialog box, which enables you to change the
name and icon for the favorite selected in the A Favorites list.
H Add Click to display the Add dialog box, which enables you to add the
current print settings as a favorite.
I Import Click to display the Open dialog box, which enables you to import
favorite settings saved as a le.
J Export Click to display the Save As dialog box, which enables you to save the
favorite settings as a le.
414 Windows Software

Canon imagePROGRAF iPF810 Specifications

Print Specifications

print resolution	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02 mm
number of nozzles (Matte Black)	5, 120 Nozzles
number of nozzles (Other Colors)	2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print-head swath	1.07 inch

Ink and Media

ink type (Dye)	Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)	Matte Black (MBK)
ink tank shipped with printer	PFI-303 (330ml) MBK, C, M, Y, K
ink tank replacement	PFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)	10" – 44" (254mm – 1118mm)
media width (Cut Sheet)	8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)	59' (18m)
maximum print length (Cut Sheet)	63" (1.6m)
media thickness	0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter	5.9" (150mm)

Power and Noise

power supply	AC 100–240V (50-60Hz)
power consumption (Maximum)	190W or Less
power consumption (Standby)	6W or Less
acoustic noise (Operation)	52dB (A) or Less
acoustic noise (Standby)	35dB (A) or Less
acoustic power	6.8 Bels or Less

Operating Environment

temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (iPF810/iPF810 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)	Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)	45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)	Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)	Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)	49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)	Approx. 768 lb. (348kg)
