Printer Driver
Media Detailed Settings Dialog Box (Mac OS X)
The Paper Detailed Settings dialog box of fers the following settings. For details on settings items, refer to
the printer driver help.
Note
T o display the Paper Detailed Settings dialog box, on the Main pane, click Settings by Media
T ype . ( P .436)
Setting Item
Description
A Media T ype
Select the paper type.
For information on the types of paper the printer supports, refer to the Paper
Reference Guide . ( P .125)
B Drying T ime Specify the time that the printer waits for ink to dry , as needed. The Drying
T ime setting is only valid for rolls.
( P .153)
C Between Pages
Specify the time the printer waits after printing a page until ejecting the
paper , as needed.
D Between Scans Specify the time the printer waits after printing a line on the page until
printing the next line, as needed.
E Roll Paper Margin for
Safety
Y ou can specify the length of a margin on the leading edge of paper to
ensure that paper susceptible to curling is held rmly against the Platen .
F Near End Margin Specify the length of the Near End Margin (the leading edge margin) of the
roll, as needed.
G Cut Speed
Select the speed of automatic cutting, as needed. Y ou can adjust this setting
if paper is not cut well when automatic cutting is used.
H Automatic Cutting Y ou can activate or deactivate Automatic Cutting and printing of cut lines,
as desired. In this list, specify Y es , No , or Print Cut Guideline .
J Mirror Specify whether to print a mirror image, as needed. Select this option to print
a version of the document or image with the left and right sides inverted.
440 Mac OS X Software

Table of Contents

Other manuals for Canon imagePROGRAF iPF810

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF810 and is the answer not in the manual?

Canon imagePROGRAF iPF810 Specifications

Print Specifications IconPrint Specifications
print resolution2400 x 1200 dpi
line accuracy±0.1% or Less
minimum line weight0.02 mm
number of nozzles (Matte Black)5, 120 Nozzles
number of nozzles (Other Colors)2, 560 Nozzles per Color
droplet size4 Picoliter
nozzle pitch (head resolution)1200 dpi x Two Rows
print-head swath1.07 inch
Ink and Media IconInk and Media
ink type (Dye)Cyan (C), Magenta (M), Yellow (Y), Black (K)
ink type (Pigment)Matte Black (MBK)
ink tank shipped with printerPFI-303 (330ml) MBK, C, M, Y, K
ink tank replacementPFI-703 (700ml) MBK, C, M, Y, K
media width (Roll Feed)10" – 44" (254mm – 1118mm)
media width (Cut Sheet)8" – 44" (203.2mm – 1118mm)
maximum print length (Roll Feed)59' (18m)
maximum print length (Cut Sheet)63" (1.6m)
media thickness0.07 – 0.8mm (2.8 – 31.4mil)
maximum roll outer diameter5.9" (150mm)
Power and Noise IconPower and Noise
power supplyAC 100–240V (50-60Hz)
power consumption (Maximum)190W or Less
power consumption (Standby)6W or Less
acoustic noise (Operation)52dB (A) or Less
acoustic noise (Standby)35dB (A) or Less
acoustic power6.8 Bels or Less
Operating Environment IconOperating Environment
temperature59 – 86 F° (15 – 30 C°)
relative humidity10 – 80% (No Condensation)
Weight and Dimensions IconWeight and Dimensions
printer dimensions (iPF810/iPF810 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF810/iPF810 PRO)Approx. 335 lb. (152kg)
printer dimensions (iPF820/iPF820 PRO)45.1" x 74.6" x 50.9" (1144mm x 1893mm x 1291mm)
weight with stand (iPF820/iPF820 PRO)Approx. 417 lb. (189kg)
package dimensions (iPF810/iPF810 PRO)49.8" x 92.5" x 62.4" (1263mm x 2384mm x 1585mm)
package weight (iPF810/iPF810 PRO)Approx. 664 lb. (301kg)
package dimensions (iPF820/iPF820 PRO)49.8" x 92.5" x 62.4" (1263mm x 2348mm x 1585mm)
package weight (iPF820/iPF820 PRO)Approx. 768 lb. (348kg)
